Топливная система и коды неисправностей
двигателя 4.5L / 6.8L John Deere





Коды неисправностей блока ECU
Ascending SPN/FMI Codes
SPN         FMI          Description
000028 03 Throttle Volts High
            04 Throttle Volts Low
000029 03 Throttle Volts High
            04 Throttle Volts Low
000084 31 Vehicle Speed Mismatch
000091 03 Throttle Volts High
            04 Throttle Volts Low
            09 Throttle Invalid
            14 Throttle Voltage Out of Range
000094 03 Fuel Rail Pressure Input Voltage High
            04 Fuel Rail Pressure Input Voltage Low
            10 Fuel Rail Pressure Loss Detected
            13 Fuel Rail Pressure Higher Than Expected
            17 Fuel Rail Pressure Not Developed
000097 00 Water in Fuel Continuously Detected
            03 Water in Fuel Signal Voltage High
            04 Water in Fuel Signal Voltage Low
            16 Water in Fuel Detected
000100 01 Engine Oil Pressure Extremely Low
            03 Engine Oil Pressure Input Voltage High
            04 Engine Oil Pressure Input Voltage Low
            18 Engine Oil Pressure Moderately Low
000105 00 Manifold Air Temperature Extremely High
            03 Manifold Air Temperature Input Voltage High
            04 Manifold Air Temperature Input Voltage Low
            16 Manifold Air Temperature Moderately High
000107 00 Air Filter Differential Pressure
000110 00 Engine Coolant Temperature Extremely High
            03 Engine Coolant Temperature Input Voltage High
            04 Engine Coolant Temperature Input Voltage Low
            15 Engine Coolant Temperature High Least Severe
            16 Engine Coolant Temperature Moderately High
000111 01 Engine Coolant Level Low
000158 17 ECU Power Down Error
000160 02 Wheel Speed Input Noise
000174 00 Fuel Temperature High Most Severe
            03 Fuel Temperature Input Voltage High
            04 Fuel Temperature Input Voltage Low
            16 Fuel Temperature High Moderately Severe
000189 00 Engine Speed Derate
000190 00 Engine Overspeed Extreme
            16 Engine Overspeed Moderate
000237 02 Vehicle Identification Number Invalid
            13 Vehicle Identification Option Code Invalid
            31 Vehicle Model Number Invalid
000611 03 Electronic Injector Wiring Shorted to Power Source
            04 Electronic Injector Wiring Shorted to Ground
000620 03 Sensor Supply 2 Voltage High
            04 Sensor Supply 2 Voltage Low
000627 01 Electronic Injector Supply Voltage Problem
000629 13 ECU Error
000636 02 Pump Position Sensor Input Noise
            08 Pump Position Sensor Input Missing
            10 Pump Position Sensor Input Pattern Error
000637 02 Crank Position Input Noise
            07 Crank Position/Pump Position Timing Moderately Out of Sync
            08 Crank Position Input Missing
            10 Crank Position Input Pattern Error
000639 13 CAN Bus Error
000651 05 Cylinder #1 Electronic Injector Circuit Open
            06 Cylinder #1 Electronic Injector Circuit Shorted
            07 Cylinder #1 Electronic Injector Mechanical Failure
000652 05 Cylinder #2 Electronic Injector Circuit Open
            06 Cylinder #2 Electronic Injector Circuit Shorted
            07 Cylinder #2 Electronic Injector Mechanical Failure
000653 05 Cylinder #3 Electronic Injector Circuit Open
            06 Cylinder #3 Electronic Injector Circuit Shorted
            07 Cylinder #3 Electronic Injector Mechanical Failure
000654 05 Cylinder #4 Electronic Injector Circuit Open
            06 Cylinder #4 Electronic Injector Circuit Shorted
            07 Cylinder #4 Electronic Injector Mechanical Failure
000655 05 Cylinder #5 Electronic Injector Circuit Open
            06 Cylinder #5 Electronic Injector Circuit Shorted
            07 Cylinder #5 Electronic Injector Mechanical Failure
000656 05 Cylinder #6 Electronic Injector Circuit Open
            06 Cylinder #6 Electronic Injector Circuit Shorted
            07 Cylinder #6 Electronic Injector Mechanical Delivery Failure
000676 03 Glow Plug Relay Voltage High
            05 Glow Plug Relay Voltage Low
000898 09 Vehicle Speed or Torque Message Invalid
000970 31 Engine Shutdown - Auxiliary Request
000971 31 External Fuel Derate Switch Active
001069 09 Tire Size Invalid
            31 Tire Size Error
001079 03 Sensor Supply 1 Voltage High
            04 Sensor Supply 1 Voltage Low
001080 03 Fuel Rail Pressure Sensor Supply Voltage High
            04 Fuel Rail Pressure Sensor Supply Voltage Low
001109 31 Engine Protection Shutdown Warning
001110 31 Engine Protection Shutdown
001347 03 Pump Control Valve Current High
            05 Pump Control Valve Current Mismatch
            07 Fuel Rail Pressure Control Error
            10 Pump Control Valve Fuel Flow Not Detected
001568 02 Torque Curve Selection Invalid
001569 31 Fuel Derate
001639 01 Fan Speed Input Missing
            16 Fan Speed Higher Than Expected
            18 Fan Speed Lower Than Expected
002000 13 Security Violation
002005 09 ACU Signal Missing
002049 09 CAB Signal Missing
002071 09 CCU Signal Missing

DTC’s Listing in Ascending 2-Digit Codes
2-Digit       SPN        FMI        Definition
11 000091 03 Throttle Volts High
12 000091 04 Throttle Volts Low
13 000029 03 Throttle Volts High
15 000028 03 Throttle Volts High
17 000653 05 Cylinder #3 EI Circuit Open
18 000110 03 Engine Coolant Temperature Input Voltage High
19 000110 04 Engine Coolant Temperature Input Voltage Low
21 000620 03 Sensor Supply 2 Voltage High
22 000620 04 Sensor Supply 2 Voltage Low
23 000100 03 Engine Oil Pressure Input Voltage High
24 000100 04 Engine Oil Pressure Input Voltage Low
25 000105 03 Manifold Air Temperature Input Voltage High
26 000105 04 Manifold Air Temperature Input Voltage Low
27 000094 03 Fuel Rail Pressure Input Voltage High
28 000094 04 Fuel Rail Pressure Input Voltage Low
29 000652 05 Cylinder #2 EI Circuit Open
31 000651 05 Cylinder #1 EI Circuit Open
32 N/Aa N/Aa When reading blink codes, signifies the start of active codes.
33 N/Aa N/Aa When reading blink codes, signifies the start of stored codes.
34 000654 05 Cylinder #4 EI Circuit Open
35 000655 05 Cylinder #5 EI Circuit Open
36 000656 06 Cylinder #6 EI Circuit Open
37 000174 03 Fuel Temperature Input Voltage High
38 000174 04 Fuel Temperature Input Voltage Low
39 000637 02 Crank Position Input Noise
000637 10 Crank Position Input Pattern Error
41 000637 08 Crank Position Input Missing
42 000190 00 Engine Overspeed Extreme
16 Engine Overspeed Moderate
43 000636 08 Pump Position Input Missing
44 000636 02 Pump Position Input Noise
000636 10 Pump Position Pattern Error
45 000637 07 Crank/Pump Position Out of Sync
48 001080 04 Fuel Rail Pressure Sensor Supply Voltage High
49 001080 03 Fuel Rail Pressure Sensor Supply Voltage Low
51 001079 03 Sensor Supply 1 Voltage High
52 001079 04 Sensor Supply 1 Voltage Low
54 000158 17 ECU Power Down Error
55 000105 16 Manifold Air Temperature Moderately High
56 000655 07 Cylinder #5 EI Delivery Failure
59 000653 07 Cylinder #3 EI Delivery Failure
61 000110 15 Engine Coolant Temperature High Least Severe
62 000110 16 Engine Coolant Temperature High Moderately Severe
63 000110 00 Engine Coolant Temperature High Most Severe
64 000111 01 Engine Coolant Level Low
65 000651 07 Cylinder #1 EI Delivery Failure
66 000652 07 Cylinder #2 EI Delivery Failure
67 000654 07 Cylinder #4 EI Delivery Failure
68 000656 07 Cylinder #6 EI Delivery Failure
71 000174 16 Fuel Temperature Moderately High
74 000100 18 Engine Oil Pressure Moderately Low
75 000100 01 Engine Oil Pressure Extremely Low
76 000654 07 Cylinder #4 EI Delivery Failure
77 001347 05 Pump Control Valve Current Mismatch
78 001347 07 Fuel Rail Pressure Control Error
79 001347 03 Pump Control Valve Current High
82 001110 31 Engine Protection Shutdown
83 000970 31 Auxilary Engine Shutdown Switch Active
84 000971 31 External Fuel Derate Switch Active
85 000094 17 Fuel Rail Pressure Not Developed
86 000094 10 Fuel Rail Pressure Loss Detected
88 N/Aa N/Aa When reading blink codes, signifies that no fault codes are in buffer.
91 000651 06 Cylinder #1 EI Circuit Shorted
92 000652 06 Cylinder #2 EI Circuit Shorted
93 000653 06 Cylinder #3 EI Circuit Shorted
94 000654 06 Cylinder #4 EI Circuit Shorted
95 000655 06 Cylinder #5 EI Circuit Shorted
96 000656 06 Cylinder #6 EI Circuit Shorted
97 000627 01 Electronic Injector Supply Voltage Problem
98 000611 03 Electronic Injector Wiring Shorted to Power Source
99 000611 04 Electronic Injector Wiring Shorted to Ground
aN/A = Not Applicable
